SID 6-22 Cordless impact driver

Cordl. impact driver SID 6-22 box #2247394

SID 6-22 with B22 55 interior finishing US version

SID 6-22 with B22 110 and belt hook in building construction EU version

SID 6-22 with B22 85 and belt hook in building construction US version

SID 6-22 with B22 110 + belt hook M EU version

Worker using a SID 6-22 with Nuron B22-85 battery for frame fastening for drywall / drylining application in interior finishing

Worker using a SID 6-22 with Nuron B22-85 battery for frame fastening for drywall / drylining interior finishing application

Power-class cordless impact driver with high-speed brushless motor and precise handling to help you save time on high-volume fastening jobs (Nuron battery platform)

Feature: LED light ring around the chuck
Chuck type: 1/4" hexagonal click-in
No load RPM: gear 1: 1800 rpm; gear 2: 2700 rpm; gear 3: 3600 rpm

Customers also searched for cordless impact driver, impact driver, impact hammer, Nuron battery platform or power class.

Customize your kit

Tool Body

Tool body with cardboard box

How many kits do you want to order?

You can not see your company prices

Please Log in or register to see your company prices.

Discounted (before tax)

TWD 10,620

Technical Data

Feature

LED light ring around the chuck

Chuck type

1/4" hexagonal click-in

No load RPM

gear 1: 1800 rpm; gear 2: 2700 rpm; gear 3: 3600 rpm

Maximum torque

150 Nm (1); 300 Nm (2); 300 Nm (3) ¹

Full hammering frequency

4250 impacts/minute

Number of gears

Dimensions (LxWxH)

138 x 68 x 206 mm

Tool body weight

0.994 kg

A-weighted emission sound pressure level

94 dB (A) ²

Tri. vibr. val for impact tightening of fasteners of the max cap of tool (ah)

13.4 m/s²

Rated voltage

21.6 V

Do not use the tool for applications where an exact torque or maximum torque is specified - there is a risk of over-tightening and damaging the screw or workpiece.
According to the applicable product standard (see the Operating Instruction for more details)

Documents

pdf Operating Instruction SID 6-22 (01), Arabic, cn, Danish, English, Estonian, Finnish, Japanese, Kazakh, Korean, Lithuanian, Latvian, Norwegian, Russian, Swedish, Turkish, Ukrainian, Chinese [ 2.9 MB ]

Download

Features & Applications

Features

Uncompromising speed – the 3600 rpm brushless motor and rapid trigger response help you save time on every single fastening
Longer battery run time – smart, efficient Nuron 22V batteries work with the brushless motor to deliver our longest ever working time per charge from a cordless impact driver
Extra-compact size – at just 137 mm from front to back, this is the ideal cordless impact driver when you need power in tight spaces
LED light ring around the chuck – for a clearer, glare-free view of your work area
Ergonomic grip – textured and contoured for more comfortable control during long periods of use, or when working overhead

Applications

Fastening jobs where a minimized time-per-fastening is essential – such as metal deck, stud framing, HVAC, formwork, prefab and glazing
Self-drilling screws – optimized for drilling through metal, then driving threads to completion
Wood screws – high-speed cordless impact driver for attaching wood to wood
Masonry screws – three gears so torque can be reduced for masonry screws such as HRD
Drilling in wood with spade bits such as WDB-S (max. diameter 25 mm)
