Very powerful TE-S demolition hammer for heavy-duty chiseling in concrete, with Active Vibration Reduction (AVR)

  • Working direction: Wall, Floor
  • Tool chuck type: TE-S
  • Weight according EPTA-Procedure 01/2003 without battery: 10.6 kg

Customers also searched for chipper chipping hammer hilti chipping hammer chipping hammer concrete or chipping tool .

Choose options

Pack size
  • 1 pc
Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted (before tax)
From TWD 40,040

Technical Data

Working direction
Wall, Floor
Tool chuck type
TE-S
Weight according EPTA-Procedure 01/2003 without battery
10.6 kg
Single impact energy
21 J
Full hammering frequency
1890 impacts/minute
Max. chiseling performance
2500 cm³/min
Dimensions (LxWxH)
587 x 141 x 326 mm
Triaxial vibration for chiseling into concrete
9.0 m/s² 1
Dust removal system available
TE DRS-B
A-weighted emission sound pressure level
90 dB (A) 2
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Features & Applications

Features

  • Powerful breaking performance thanks to exceptional impact energy and innovative Hilti chisels
  • Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
  • High robustness and long lifetime due to separate lubrication chambers
  • Power reduction button for use on lighter materials and for greater precision in controlled breaking jobs
  • Optional TE DRS-B dust removal system collects up to 95% of fine dust

Applications

  • Demolition work on walls
  • Correction work on floor slabs
  • Breaking out openings for doors and windows
  • Making penetrations for ducts and pipes

For approval or certificate information, please see individual items.

Services

Service icon for Tool Services

Hilti Tool Service

  • 3 or free, get the tool serviced and cleaned in 3 days flat or repair is free of charge
  • After 2 years repair costs are capped
  • Service is free of charge up to 2 years, including wear & tear, pick-up and delivery
  • 3-month no-cost period after each repair
More information about Tool Services

LifeTime Services

  • 2 years no repair costs from date of purchase, including wear & tear parts, shipping and labor
More information about LifeTime Services
